Ascendo Immersive Audio The12 Be Pro Passive Wedge

SKU: The12ProBePassiveWedge
The12 BE PRO PASSIVE WEDGE is an enormously dynamic and powerful speaker. Its high efficiency and high-power handling allow it to reach reference volume levels and obtain an impressive cinema sound experience even with low amplifier power.
119 999,- inkl. mva
Antall:

Bestillingsvare

25
70 × 40 × 30 cm

Send meg en epost når denne er på lager

Beskrivelse

Bruksanvisning >>






The design objective for this model was to offer a pre-angled version of The12 BE PRO PASSIVE that can be installed in multiple locations where angling the speakers is mandatory. Such locations include but are not limited to front wide, Atmos and DTS top front and rear, front or rear high surrounds, side surrounds etc.

The driver design is perfect for wide angle axi-symmetric radiation to cover a large listening area, with its 30-degree pre-angle meeting the requirements of most 3D home theater builds according to current CEDIA, Dolby and DTS specs. The very flexible speaker mounting and orientation options ensure best possible localization, immersion, and tonal balance at the main listening position while minimizing localization shifts for side seats.

The12 BE PRO PASSIVE WEDGE is an enormously dynamic and powerful speaker. Its high efficiency and high-power handling allow it to reach reference volume levels and obtain an impressive cinema sound experience even with low amplifier power.

Omtaler

Det er ingen omtaler ennå.

Bare innloggede kunder som har kjøpt dette produktet kan legge igjen en omtale.

SPESIFIKASJONER



Speaker type Time coherent  12″  beryllium point-Source
Enclosure type Vented
Passive / Active Passive
Cont./peak output 126 dB cont. / 129 dB peak
Frequency Range 75 Hz to 21 kHz
Efficiency 97 dB / 1W/m
Power Handling 900W
Impedance 8 Ω
Woofer 12″, 300mm
Tweeter 1.4″ (Throat) Beryllium compression driver
Directivity Horizontal x Vertical in Deg° 85° x 85°
Input Terrminal Neutrik Speakon
Enclosure Internally braced birch ply
Width 19,69″ / 500 mm Horizontal
Height 17,72″ / 450 mm Horizontal
Depth With Plug 7,11-11,74″ / 180,61 – 228,17 mm, Angle 15°
Depth grill  0,39″ / 10 mm
Weight 50,70 lbs / 23,0 kg
Finish Structural paint black
Custom colour options Genuine piano lacquer (12 layers): matt lacquer: colour of choice, other finishes upon request
Shape customization Possible, upon request
Mounting 4 x  wall brackets for horizontal and vertical installation,  VESA 200 mounting option
