Nord Acoustics NC1200DM Hypex NCore Stereo Effektforsterker 2x700W -CUSTOM BYGGET-

Bestillingsvare

64 999,-65 999,- inkl. mva

NB! Hver enkelt forsterker produseres på fabrikken etter dine spesifikasjoner, hvilket betyr at dette er et tilvirkningskjøp der vi ikke kan tilby retur / angrerett. Produksjonstid er 7-10 dager, og leveringstid til deg er normalt innen 14 dager.

NYHET! Stereo effektforsterker (finnes også som monoblokk) basert på NCore modulene til Hypex leverer ekstremt høy lydkvalitet! NC1200-modulen er toppmodellen i serien som så langt har vært forbeholdt konstruksjoner til minst 100.000.-.

Nullstill
Varenummer: NC1200DM_CUSTOM Kategori: Brand: Nord Acoustics

Beskrivelse

NB! Hver enkelt forsterker produseres på fabrikken etter dine spesifikasjoner, hvilket betyr at dette er et tilvirkningskjøp der vi ikke kan tilby retur / angrerett. Produksjonstid er 7-10 dager, og leveringstid til deg er normalt innen 14 dager.



NYHET! Stereo effektforsterker (finnes også som monoblokk) basert på NCore modulene til Hypex leverer ekstremt høy lydkvalitet! NC1200-modulen er toppmodellen i serien som så langt har vært forbeholdt konstruksjoner til minst 100.000.-.

Informasjon fra produsent:

The Stereo Dual Mono has 2 x Hypex NCore NC1200, 2 x Hypex SMPS1200A700 PSU and 2 x Nord One NC1200 REV A Input Buffer Boards with choice of OP Amps in a Stereo Case. Will also accept previous 8 pin Sparkos and Sonic Imagery OP Amps.

Switchable ON OFF DIM front LED.

OVERVIEW OF NORD ONE SE NC1200 SIGNATURE POWER AMP

We are exited to offer our new Hypex NC1200 based amplifier using Hypex’s best module and Nord Input buffer board.

Please don’t ask us to compare to our NC500 MKII amp. Yes the NC1200 is better in every way, but then our NC500 MKII is better than most amps costing up to £10K. They are distinctly different priced amps if you want the best and can afford the NC1200, its the amp to choose.

Until recently the Hypex NC1200 was only available to a few Manufactures and with amplifiers costing upwards of £10K. We had access to the module but with a minimum pricing policy of £6.5K decided was to expensive for a boutique manufacture like Nord. A recent change in pricing policy means we are free to price as we feel fit. Without the expensive infrastructure of distributors , dealers, Reps, advertising, shows and other expense we can bring you this exalted amplifier at a reasonable cost.

Using Hypex NC1200 modules powered by Hypex SMPS1200A700 PSU’s and a bespoke Nord Buffer designed specifically for the NC1200 and housed in our SE case work.

The  amp is packed with high end components from mains inlet to the speaker binding posts.

Furutech FI-06  solid Copper Gold IEC mains inlet with Furutech FP-SO22N mains cable throughout. Furutech FT-786F R Rhodium XLR Sockets. WBT­-0705Ag Signature Nextgen Solid Silver Conductor binding posts and connected by Neotech UP-OCC 14AWG Solid OCC Copper wire. Synergistic Research Blue Fuse. No sonic stone unturned.

The new NC1200 bufferboard uses two Op Amps per channel and runs even further into Class A delivering up to 250mA of Class A current fed into the Hypex NC1200 module. The result is more tonal depth, dramatic improvement in bass, even greater depth of soundstage, slightly more detail all wrapped in a balance of rich texture and harmonics, bottom-end presence , amazing dynamics, exquisite resolution in the mids and upper frequencies, and a fully revealed, fully dimensional sound stage  Headroom and listening volumes have increased and all combine in a totally musical non fatiguing Class A sound. Gone, if there was any hint, of solid state amplifie

SPECIFICATIONS

  • Beautiful Quality Japanese made Case with a Fine Brushed Anodized Finish. Solid and Resonance Free. CNC Machined In House.

  • Solid Polished Aluminium  Isolation Feet with Rubber Inserts.

  • Furutech FI-06 Solid Copper Gold Plated IEC mains Inlet

  • Synergistic Research Blue SR Quantum Fuse with Graphene.

  • Furutech FP-SO22N Mains Wiring Throughout

  • Furutech FT-786F R Rhodium XLR Sockets.

  • WBT­-0705Ag Signature Nextgen Solid Silver Conductor Binding Posts (Copper Version available no cost option)

  • Neotech UP-OCC 14AWG solid OCC Copper Speaker Output wire.

  • Hypex QuietConduit NCore Cable for XLR Connection.

  • 19mm Brushed Stainless Steel Dimmable LED Front Switch.

  • Buffer Uses, Audio Grade Ultra Quite Polystyrene Capacitors in Audio stage, 1% Metal Film Resistors, Panasonic Electrolytic Capacitors in Power Section.

  • A Dash of Passion, Pride, And Practice ensure a superbly made Amplifier.



• Two Hypex NCore NC1200 Modules (Stereo)

• Two Hypex SMPS1200A700 Power Supply (Stereo)

• Nord One NC1200 REV A Input Buffer

  Choice of Sparkos SS2590 or Sonic Imagery 990Enh Op Amps.       also accept previous 8 pin Sparkos and Sonic Imagery OP Amps.

• Stereo True Dual Mono Design

• SNR 137dB

• Distortion: THD+N – – 0.004 % 20Hz

• Frequency Response: 0 – 50k Hz +0/-3dB

• Low Distortion: THD+N – – 0.001 % 20Hz

• High Input Impedance 51K

• Input Sensitivity 8ohm 2.52Vrms 10.24dBu

• 26.4 dB Gain

• Ultra High Damping Factor

• Ultra High Damping Factor

• High Current Output Max 40A Capable of driving 2ohm

  (for the Most Demanding of Speakers)

   1200W 2ohm

   700W 4ohm

   400W 8ohm

• Frequency Response: 0 – 50k Hz +0/-3dB

• XLR Balanced Inputs

• 2 Years Warranty

• Stereo Case W 430mm D 331mm H 88mm

• Weight 9Kg

• Mono Block Case W 280mm D 231mm H 70mm

• Weight 4.5Kg

• 2 Years Warranty

HYPEX NC1200


Hypex NC1200 is the very best Class D amplifier module available, and sound Incredible.

NORD NC1200 BUFFER

REV A

Nord NC1200 Buffer REV A.png

The new NC1200 REV A buffer is based on our acclaimed new REV D NC500 buffer and specifically developed for the NC1200.

HYPEX SMPS1200A700

15 SMPS1200A700 PSU.png

The SMPS is a ultra quite low EFI power supply designed to extract the maximum performance from the NC1200 and offers superior performance than a traditional linear PSU.

WBT-O705 SOLID Ag BINDING POSTS

WBT 0705Ag.jpg

The soul of the new top of the range binding post WBT-0705 is a one-piece design, removing all unnecessary transition  resistance. The signal conductor solid Silver (Copper version available no cost option leave note in checkout) is embedded in a matrix of fibre glass and mineral reinforced plastic and equipped with an anti-magnetic stainless steel strut for perfect strain relief. An additional elastomer damping ring keeps oscillations away from the contact level and successfully suppresses any kind of contact microphonics resistance.

FURUTECH XLR FT-786 RHODIUM


Furutech’s beautifully finished top of the range and just as importantly beautiful sounding XLR sockets are the result of meticulous engineering and careful audition of various materials. The FT-786F features a Rhodium conductor for minimal impedance set in a super heat resistant liquid crystal polymer resin and a nonresonant nylon/fiberglass housing containing Furutech’ s Piezo Ceramic Damping Material. Unique to Furutech FT-786F and FT-785M XLR sockets are special nonmagnetic stainless steel plates that are incorporated into the piezo compound construction using a special Furutech patent-pending process. Pure Transmission principles at their finest!

SYNERGISTIC SR BLUE FUSE

BLUE FUSE.JPG

The new SR BLUE Quantum Fuse was developed over a two year period and represents our most advanced UEF Technology to date and is the very top of the range. At its heart is a completely new UEF / Graphene coating that delivers a dramatic increase in resolution and holographic realism over SR Black. And thanks to a new conditioning process, break-in time is cut in half. In fact a brand new out-of-the-box BLUE Fuse should significantly out perform a fully broken-in BLACK Fuse and it only gets better from there with full performance after 200 hrs of continues power. To find out how good your components really are audition the new SR BLUE Quantum Fuse today.

NEOTECH UP-OCC SOLID COPPER SPEAKER OUTPUT WIRE

neotech-soct-14-wiring-up-occ-ptfe-2mm-.

The UP OCC process for refining copper was developed and patented by Professor Ohno of the Chiba Institute of Technology in Japan. The licensed to use this manufacturing process is incredibly popular for the production of wire and cable products for the audio/video industry. UP OCC stands for Ultra-Pure, Ohno Continuous Casting. In conventional processing, hot molten copper is poured into a cooled mold for extrusion, resulting in multiple, fractionated crystal structure. While the copper may be “pure” in the sense of measuring gas impurities in the copper in comparison to standard copper refining techniques. Oxygen Free Copper (OFC) has undesirable effects that lead many to use more expensive materials such as silver for their conductive strands. As developed for A/V cable use, the OCC process utilizes a heated mold for casting and extruding, with cooling taking place in a separate process. The result is a larger crystal size and increased purity that approaches the 6N, 99.9998%! Looking at it another way, traditional copper has oxygen impurities of 200 to 500 parts per million (PPM), while traditional OFC copper reduces that to less than 10 PPM. With the OCC process, the figure is cut in half to less than 5 PPM of oxygen, and less than 0.25 PPM of hydrogen (compared to 0.5 PPM for OFC). With these results, the OCC process creates “ultra-pure” copper. The benefits of UP-OCC are as following: • A true unidirectional copper crystal that is as free from impurities as possible to prevent corrosion • Flexibility and fatigue resistance without impairing conductive characteristics • Low electrical resistance • Rapid signal transmission • Corrosive-resistant • Non-crystal boundaries

FURUTECH FP-S022N Alpha Nano-OFC Power Cable

The Furutech Nano-OFC power cord uses one of the finest conductors their engineers have designed the Alpha Nano OFC. They combined their legendary Alpha-OFC conductors, which are treated cryogenically and demagnetized in a patented two-step process, with a new transmission enhancer known as Nano Liquid. The molecules in Nano Liquid are so small (approximately 8 nanometers in diameter, or 8/1,000,000th of a millimeter) that they finely “coat” the Alpha-OFC and smooth out all microscopic surface irregularities that can affect both signal transfer and impedance. That means, quite simply, that there is a greater contact area for the conductor.

Nano Liquid is created by precisely mixing super-micro particles made of both gold and silver, along with a dispersion of Squalene oil. The engineers at Furutech found that they could affect the ultimate sound quality by carefully varying the ratios of the gold, silver and oil. After many extensive tests, the engineers agreed upon the ratio now used in our Nano Liquid. In essence, they “tuned” the Nano Liquid until they arrived at a balanced, musical sound a sound that could only be the result of the purest transmission of AC power.

Tilleggsinformasjon

Vekt 20 kg
Dimensjoner 50 × 40 × 30 cm
